Natural Gas Urban Distribution Station

 It has the functions of detection, filtering, metering, pressure regulation, heat tracing, odorization, distribution and remote telemetry. /Remote control and other functions. City gate stations can be equipped with imported flow meters and flow computers, as well as domestic high-quality flow meters. The city gate station can also have the functions of automatic cut-off and automatic relief of ultra-high/low pressure outlet pressure. City gate stations can work in remote telemetry/remote control mode. City gate stations can adopt heat preservation and heat mixing measures. City gate stations can adopt different structural forms according to user needs.

The system is all standard configuration, and the main and auxiliary voltage regulators are made of internationally renowned brands. Other parts are all high-quality domestic products, achieving high quality, high reliability and high precision work. The pressure regulating station is equipped with a filter with a unique structure, with a filtration accuracy of 5 μM. In addition, the differential pressure gauge can reflect the degree of dirtiness of the filter element, and users can replace the filter element in time. The pressure regulator is equipped with an ultra-high/low-pressure automatic cut-off device and a safety relief device to ensure that the outlet pressure is automatically maintained within a certain range as the gas consumption changes and the inlet pressure fluctuates.

This equipment has excellent expansion performance and can add system functions such as flow meter, pressure recording, silencer, monitoring, insulation and heat mixing measures according to user requirements. The pressure regulating station has a compact design, simple installation process, and a unique patented box design that is more beautiful. The surface of the box has been phosphated and anti-rust treated, making it suitable for indoor or outdoor installation, and the safety distance can be greatly reduced. The equipment has undergone air tightness testing before production, and its control points are strictly set according to user requirements to ensure easy and convenient on-site operation for users.

Gas enters the pressure regulating station and passes through insulating joints, inlet valves, filtering devices, metering devices, reheating devices, pressure regulating and shutoff devices, odorizing devices, and outlet valves to adjust the pressure to the outlet pressure required by the user. The system can be set as needed. The corresponding station control system, odorizing system, and various structural forms and functions are available for users to choose from.
